- Sku:
- Vendor: HIKVISION
HIKVISION DS-D4512CB108-2FQ 108'' LED AIO 1.25mm Pixel Pitch Glue on Board FHD 16:9 Android 14 16GB/256GB
HK$120,000.00
108'' LED AIO (Non-Touch), Full color LED screen, Indoor, Pixel pitch 1.25mm, Glue on board, 1080P resolution, 16:9, after Module Calibration 600nits. Hikvision control system.
Wooden box transportation (1 box). Built-in wall-mounting bracket, Floor-standing Bracket needs to be purchased separately
- High Integration Design: The mainboard integrates the control system, Android, network processing, and video interface modules into a single unit, significantly boosting system reliability. It allows flexible plug-and-play module installation for easy setup and maintenance.
- Lightweight Solution: Leveraging high-load signal processing technology, the design enables full-screen data transmission using just one internal signal cable.
- Innovative Structural Design: Featuring carefully selected Scandinavian-inspired fabric and an ultra-narrow bezel, the product delivers a refined aesthetic. The innovative quick-lock mechanism ensures secure connections with a simple twist, enhancing alignment precision.
- Easy and Quick Installation: The cabinet employs a segmented pre-assembly design, facilitating modular column-based installation for quick and efficient setup.
- Enhanced Performance: Seamless switching between Android and Windows systems improves adaptability across various scenarios. The WonderOS 3.0 system is optimized for large-screen UI interactions, providing an intuitive user experience.
- Versatile Functionality: Supports multi-device wireless screen sharing, whiteboard capabilities, conference recording, welcome message display, and other practical features for diverse applications.
| Product Model | ||
| Product Model | DS-D4512CB108-2FQ | |
| Display | ||
| White Balance Brightness | 600 cd/m² | |
| Color Temperature | 3000-10000K adjustable | |
| Viewing Angle | 160° (H)/160° (V) | |
| Brightness Uniformity | ± 0.003Cx，Cy | |
| Color Uniformity | ≥ 97％ | |
| Screen Size | 108inch | （275.3cm） |
| Display Resolution | 1920 × 1080 | |
| Contrast Ratio | 3000:1 | |
| Active Screen Area | 3.2 ㎡ | |
| Display Ratio | 16:9 | |
| Optimal View Distance | 3 m | |
| Built-in System | ||
| Operation System | Android 12-14, windows 10-11 (optional with OPS accessories) | |
| Processor | Android: Max. 1.5 GHz, A76 × 4 + A55 × 4 | |
| Windows: i5-11390H | ||
| Memory | Android: 16GB | |
| Windows: 16GB | ||
| Built-in Storage | Android: 256 GB | |
| Windows: 256 GB | ||
| NIC | Integrated gigabit LAN with router mode enabled | |
| CPU Clock Speed | 2.4 GHz | |
| Wireless | Supports concurrent operation in station and access point (AP) mode, enabling Wi -Fi | |
| hotspot functionality. | ||
| Bluetooth | Integrated BLE module compliant with Bluetooth 5.1 and backward-compatible | |
| versions. | ||
| Interface | ||
| Video & Audio Input | LINE IN × 1, HDMI IN × 4 | |
| Video & Audio Output | LINE OUT × 1, SPDIF OUT × 1，HDMI OUT × 1 | |
| Data Transmission Interface | Front Panel Interfaces: USB 3.0 × 2, Type-C × 1 | |
| Internal Slot at Bottom: USB 2.0 × 1 | ||
| Control Interface | 1 × RS232 serial port | |
| Speaker | Built-in 2*18 W speaker | |
| Cabinet | ||
| Pixel Configuration | SMD Triad LED (with glue) | |
| Pixel Pitch | 1.25 mm | |
| Pixel Density | 640000 dots/m² | |
| Cabinet Material | Aluminum alloy | |
| Maintenance Method | Front maintenance | |
| Processing Performance | ||
| Driving Method | Constant current driving | |
| Frame Frequency | 30 Hz/60 Hz | ||||||||||
| Refresh Rate | 3840 Hz | ||||||||||
| Grey Level | 16 bit | ||||||||||
| Key Material | |||||||||||
| Power Specification | 4.2 V/40 A (Cabinet Power Supply), 19 V/8 A (Control Power Supply) | ||||||||||
| Power | |||||||||||
| Standby Consumption | ≤ 0.5 W | ||||||||||
| Short Circuit | 220V, 20A | ||||||||||
| Max. Consumption | ≤ 1500 W | ||||||||||
| Average Consumption | ≤ 500 W | ||||||||||
| Input Voltage | 110~240 VAC，50/60 Hz (110V with Low-Voltage Power Cord) | ||||||||||
| Working Environment | |||||||||||
| Working Temperature | -10 to 40 °C (14 to 104 °F) | ||||||||||
| Working Humidity | 20% to 80% RH (non-condensing) | ||||||||||
| Storage Temperature | -10 to 50 °C (14 to 122 °F) | ||||||||||
| Storage Humidity | 10% to 90% RH (non-condensing) | ||||||||||
| General | |||||||||||
| With Base: 2411.6 (W) mm × 2274.95 (H) mm × 707.5 (D) mm | |||||||||||
| Product Dimension (W × H × D) | Without Base: 2411.6 (W) mm × 1475.9 (H) mm × 47.1 (D) mm | ||||||||||
| Screen size: 2400 (W) mm × 1350 (H) mm | |||||||||||
| Mounting Type | Wall Mounting / Mobile Floor Standing Bracket Mounting (Packaging Includes | ||||||||||
| Wall-mount Bracket by default.) | |||||||||||
| Packing Method | 1 Wooden case package | ||||||||||
| Package Dimensions (W × H × D) | 1494 (W) mm × 1239 (H) mm × 454 | (D) mm (58.52 | '' × 48.78 | '' × 17.87 '') | |||||||
| Net Weight | 85 kg (187.4 lb.) | ||||||||||
| LED Module Spare Parts ×4, Multilingual Manual ×1, Bottom Panel Connecter X1, Wall | |||||||||||
| Packing List | Mounting Bracket X1, Cables (OPS Power cable, OPS Signal Cable, Main Power Cable, | ||||||||||
| Ethernet Cable, Cabinet Cascase Power Cable), Accessories (Lamps, IC, Screws, | |||||||||||
| Expansion Bolt, Tools, etc.) | |||||||||||
| Panel | |||||||||||
| Indicator | Red: The device is standby. | ||||||||||
| Blue: The device is powered on. | |||||||||||
| Button | On/Off/Sleep button × 1 | ||||||||||
